Frame
Fargo Triple Butted CroMoly
Color
Dark Grey
Fork
Cutthroat Carbon Deluxe
Headset
FSA Orbit ITA
Front Hub Axle
Salsa Deadbolt UL thru-axle, 15 x 135L, TP=1.5, TL=12
Rear Hub Axle
Salsa Deadbolt UL thru-axle, 12 x 180L, TP=1.5, TL=20
Weight
3.488kg / 7.69 lbs (includes fork, headset, front/rear thru axles, seat collar, alternator plates)
Frame Spec
Design Wheel/Tire Sizes
29 x 2.2″
Alternate Wheel/Tire Sizes
27.5 x 3.0″
Max Tire Outer Diameter
29″ wheels: 41–76mm (1.6″–3.0″) SM – XL; 41–66mm (1.6″ – 2.6″) XS 27.5″ wheels: 47–76mm (1.85″–3.0″) 26″ wheels: 70–76mm (2.75″–3.0″)
Frame Construction
Triple-butted CroMoly Steel
Fork Construction
Carbon
Suspension Fork Length (Travel)
506mm (100 mm travel)
Rigid Fork Length
480mm axle-to-crown
Fork Offset
51mm
Rear Spacing
148mm; 142mm thru-axle or 135mm quick-release with Alternator Reduction Plates
Rear Brake (Rotor)
Flat mount (160–180mm rotor)
Front Brake (Rotor)
Flat mount (160–180mm rotor), flat mount frame standard (35 mm thickness), 42 mm bolt length
Headset – Upper
ZS44
Headset – Lower
EC44
Front Spacing
110 x 15 mm thru-axle
Steerer Tube
28.6mm, Tapered
Crown Race
40mm
Seatpost
27.2mm
Dropper Post Compatible
No
Seatpost Clamp
32.0mm
Front Derailleur Clamp
148mm rear spaced: high direct-mount (29mm offset) with Problem Solvers bracket (FS1328) 142mm rear spaced: high direct-mount (26.5mm offset) with 34.9mm clamp Problem Solvers Bracket (FS1323)
Bottom Bracket
73mm BSA, threaded
Crankset (Max Ring)
1x crankset: 36t max. Boost and 34t non-boost or 46t Gates Belt Drive Sprocket; 2x crankset: 42/28t max. Boost and Non-Boost
Accessory Mounts
Rack Mounts Frame: Yes; Rack Mounts Fork: Yes, low-rider compatible. Salsa Down Under rack recommended.
Bottle Mounts
Frame: XS: Two; SM–XL: Three; Fork: One set of Three-Pack mounts on each fork leg
